Advantages:
1. High speed: high-performance galvanometer scanning system makes the marking speed up to 7000mm/s.
2. High precision: the re-position accuracy is up to 0.0012mm.
3. Integrated and compact: small and compact size, easy to carry, save production space.
4. 10 years long lifetime: adopt fiber laser as pumping source, the lifetime can reach as long as 100,000 hours. One fiber laser engraving machine can work for more than 10 years without any consumables.
5. Powerful control system: support PLT, BMP, DXF, JPG, TIF, AI and other format files that output from CorelDraw, AutoCAD, Photoshop etc.
6. Hand-wheel lifting system, easy to operate and easy to use. The laser focal length can be adjusted up and down according to different kinds of materials and marking thickness.
7. The safety glasses can effectively filter the infrared and ultraviolet arcs emitted by the laser when working. The protection wavelength is 200-450nm/800-2000nm/1064nm to protect the eyes from injury.
8. Rotary attachment is optional, diameter 80mm (50mm available), engrave and mark inside and outside ring jewellery.
Technical parameters:
ModelST-F20 | F30 | F50 | F100
Laser power20W | 30W | 50W | 100W
Laser output1 - 100% software setting
Wave length of laser1064nm
Marking area110*110mm
Optional marking area75*75mm, 150*150mm, 200*200mm
Marking speed鈮?000mm/s
Minimum line width0.01mm
Minimum character0.15mm
Repeated accuracy0.0025mm
Fiber laser sourceRaycus from China
Life time of fiber laser source100,000 hours
Beam qualityM2 <1.6
Focus spot diameter<0.01mm
Laser repetition frequency20kHz~100kHz
Cooling waysForce-air cooling
Operation systemWindows XP/Vista/7/8/10
Power supply110V卤10% 60HZ, 220V卤10% 50HZ
Gross power鈮?KW
Process MaterialAll metals and part of non-metal materials
Support formatPLT, BMP, DXF, JPG, TIF, AI etc
PackageStandard wooden box for export
Warranty timeTwo years
Operating temperature0 - 40掳C
Operating humidity5 - 95%
Packaging size94x90x162cm
Total weight150KG
Applicable Industries:
Advertising, nametag, tag, precision instruments, buckle, kitchenware, knives, cooker, stainless steel products, aerospace equipment, integrated circuit chips, computer accessories, signs molds, elevator equipment, wire and cable, industrial bearings, building materials, hotel kitchen, pipelines, sanitary ware, battery industry, IT industry etc.
Applicable Materials:
1. All metal materials like alumina, stainless steel, steel, copper, brass, gold, silver,titanium,etc.
2. Some nonmetal materials like plastics, electroplating materials, coating materials, rubber, epoxy resin, ceramic, ABS, PVC, PES ,etc.Laser Marking Machine price
